| Frame |
Aluminum, Smooth Welding, 10x135mm QR |
| Fork |
Suntour XCT-30 DS Coil, 100mm, 46mm offset, 9x100 QR |
| TRANSMISIÓN |
| Rear Shifter |
Shimano Cues SL-U4000, 9sp |
| Rear Derailleur |
Shimano Cues RD-U4000, 9sp, GS |
| Crankset |
Prowheel Alloy, 30T, 170mm (S-M), 175mm (L - XXL) |
| Bottom Bracket |
Cartridge, ST 73mm, 113mm axle length |
| Cassette |
Shimano Cues CS-LG300-9, 11-46T, 9sp |
| Chain |
KMC Z9 |
| FRENOS |
| Front Brake |
Tektro HD-M275, Resin pads |
| Front Brake Rotor |
Tektro. 160mm rotor, 6-bolt |
| Rear Brake |
Tektro HD-M275, Resin pads |
| Rear Brake Rotor |
Tektro. 160mm rotor, 6-bolt |
| Brake Levers |
Tektro HD-M275 |
| COMPONENTES |
| Handlebar |
6061 Alloy DB, 750mm (S) / 780mm (M,L,XL,XXL) 30mm rise |
| Stem |
Alloy 50mm Length, 31.8mm Clamp |
| Seatpost |
Alloy 31.6mm, 300mm (S), 400mm (M/L/XL/XXL) length |
| Headset |
Zero Stack, 1-1/8" Steer, ZS44/28.6 | ZS44/30 1 1/8" |
| Headset Spacer |
3x10mm |
| Saddle |
Norco XC, Steel Rail |
| Grips |
DDK lock-On, 139mm length |
| Pedals |
Nylon Flat Pedal |
| Seatpost Clamp |
Norco Alloy QR, 34.9mm ID |
| RUEDAS |
| Front Hub |
Formula DC-1420 , 9x100mm QR, 32h, 6-bolt |
| Rear Hub |
Formula DC-1422,10x135mm QR, HG, 32h, 6-bolt |
| Rims |
DP 27 Rims, 27mm ID, 32H |
| Front Tire |
Maxxis Forekaster, 29x2.25" (27.5X2.25"size S), Wire |
| Rear Tire |
Maxxis Forekaster, 29x2.25" (27.5X2.25"size S), Wire |
| Spokes/Nipples |
Stainless Steel, 14g |
| Weight |
15.27 kg (33.6 lbs) |
| Weight Size |
L |
