| Características | • Especificaciones
• Technical Specifications
• Interface:USB 3.1 (Gen 1) Type C
• Video Input:HDMI 2.0
• Video Output (Pass-Through):HDMI 2.0
• Audio Input:HDMI 2.0
• Audio Output (Pass-Through):HDMI 2.0
• Max Pass-Through Resolutions:2160p60 HDR /1440p144 / 1080p240
• Max Record Resolutions:2160p30 / 1440p60 / 1080p120 / 1080p60 HDR
• Supported Resolutions (Video input):2160p, 1440p, 1080p, 1080i, 720p, 576p, 480p
• Record Format:MPEG 4 (H.264+AAC) or (H.265+AAC)*
• Dimension (W x D x H):112.6 x 66.2 x 26 mm (4.43 x 2.6 x 1.02 in)
• Weight:116 g (4.09 oz.)
• Notes:
• *H.265 Compression and HDR are supported by RECentral
• LGU does not support viewing/recording/streaming of HDCP protected signals
• System Requirements(For dedicated streaming PC) Operating system: Windows® 10 x64 or later (Support UVC Protocol)
• For 4Kp30 or 1080p120 (4Kp60 HDR pass-through supported)
• Desktop:
• Intel® Core™ i5-6XXX or above
• NVIDIA® GeForce® GTX 1060 or above
• 8 GB RAM (*Dual-channel)
• Laptop:
- Intel Core i7-7700HQ or above
- NVIDIA® GeForce® GTX1050 Ti or above
- 8 GB RAM (*Dual-channel) *You have to set your memory on dual channel mode in your computer system. Please see attachment: attachment (Link)
• For 1080p60 (4Kp60 HDR pass-through supported)
• Desktop:
- Intel® Core™ i5-4440 3.10 GHz or above
- NVIDIA® GTX 660
- 4 GB RAM (8 GB recommended)
• Laptop:
- Intel Core i7-4810MQ
- NVIDIA® GeForce® GTX 870M or above
- 4 GB RAM (8GB Recommended)
• Mac system requirement : Operating system: MacOS High Sierra 10.13
• Requires an Apple Thunderbolt 3 (USB‑C) Cable (0.8 m)
• For 4Kp30 or 1080p120 (4Kp60 HDR pass-through supported)
• iMac:
- 3.6GHz quad-core Intel Core i7
- Radeon Pro 555 with 2GB of VRAM
- 16GB of 2400MHz DDR4 memory
• MacBook Pro:
- 2.8GHz quad-core Intel Core i7
- Radeon Pro 555X with 2GB of GDDR5 memory
- 16GB 2133MHz LPDDR3 memory
• For 1080p60 (4Kp60 HDR pass-through supported) :
• iMac:
- 3.6GHz quad-core Intel Core i7
- Radeon Pro 555 with 2GB of VRAM
- 16GB of 2400MHz DDR4 memory
• MacBook Pro:
- 2.6GHz quad-core Intel Core i7
- Radeon Pro 450 with 2GB of GDDR5 memory
- 16GB of 2133MHz LPDDR3 onboard memory |
