| Características | • Model MPW-7001-ACAAG
• ATX Version ATX 12V V2.52
• PFC Active PFC
• Input Voltage 100-240V
• Input Current 10-5A
• Input Frequency 47-63Hz
• Dimensions (L x W x H) 140 x 150 x 86 mm
• Fan Size 120mm
• Fan Bearing HDB
• Efficiency ≥90% @ Typical Load
• 80 PLUS Rating 80 PLUS Gold
• ErP 2014 Lot 3 Yes
• Operating Temperature 0-40°C
• Power Good Signal 100 - 150 ms
• Hold Up Time ≥15ms at 100% load
• MTBF >100,000 Hours
• Protections OVP, UVP, OPP, OTP, SCP, OCP
• Regulatory CB, cTUVus, TUV, CE, RoHS2.0, FCC, CCC, BSMI, KC+KCC, BIS, EAC
• ATX 24 Pin Connectors 1
• EPS 4+4 Pin Connectors 1
• EPS 8 Pin Connector 1
• SATA Connectors 6
• Peripheral 4 Pin Connectors 3
• PCI-e 6+2 Pin Connectors 4
• Series G Series
• 80 Plus Gold
• Modular Non Modular
• Wattage 500 to 750W |
