PRODUCT NUMBER MLX-D24M-A18PK-R1
EXTERIOR COLOR BLACK
CPU SOCKET LGA1700, LGA1200, LGA2066, LGA2011-V3, LGA2011, LGA1151, LGA1150, LGA1155, LGA1156, AM5, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1
RADIATOR MATERIAL ALUMINUM
RADIATOR DIMENSIONS 277 X 119.6 X 27.2 MM / 10.9 X 4.7 X 1.1 INCH
PUMP DIMENSIONS 81.2 X 76 X 57.8 MM / 3.19 X 3 X 2.3 INCH
PUMP MTTF 70,000 HOURS
PUMP NOISE LEVEL < 10 DBA
POWER CONNECTOR 3-PIN
PUMP RATED VOLTAGE 12 VDC
PUMP POWER CONSUMPTION 2.36 W
FAN DIMENSIONS (L X W X H) 120 X 120 X 25 MM / 4.7 X 4.7 X 1 INCH
FAN QUANTITY 2 PCS
FAN LED TYPE NON-LED
FAN SPEED 650-1800 RPM 5%
FAN AIRFLOW 62 CFM (MAX)
FAN NOISE LEVEL 8 - 27 DBA
FAN PRESSURE 2.5 MMHO (MAX)
FAN LIFE EXPECTANCY 160,000 HOURS
FAN POWER CONNECTOR 4-PIN (PWM)
FAN RATED VOLTAGE 12 VDC
FAN RATED CURRENT 0.15A
RAM CLEARANCE N/A
WARRANTY 2 YEARS
RADIATOR SIZE 240
SERIES MASTERLIQUID
COOLER TYPE LIQUID COOLER
NOTE FOR LGA 1700 MOUNTING KITS, YOU MAY OBTAIN THROUGH THE CM STORE, REGIONAL RESELLERS AND DISTRIBUTORS. IT'S COMPATIBLE WITH AMD AM5 ALTHOUGH THE PACKAGE MAY NOT STRESS IT.
